Used UDR 650 Drilling Rigs
Registered dealer · NSW
Price disclosure is supplied by the seller. If the price is listed as Ex GST, an additional 10% GST may be payable. Please confirm the final purchase price directly with the seller before proceeding.
Description
UDR 650 truck-mounted drill rig, commissioned mid-2023 following extensive refurbishment and upgrade program. Showing 9,202 hours. Highly updated unit with significant recent mechanical and hydraulic investment across both rig and carrier truck.
Specifications:
Make: UDR
Model: 650
Rig Hours: 9,202
Commissioned: Mid 2023
Configuration: Truck-mounted drill rig
Rig Equipment / Systems:
PTO-driven onboard air compressor
New water pump
New fan belts
New radiator core
Recent full service (oil and filters)
New rod & piston seals to main feed ram
New dump mast ram
New mast raise rams (rods & seals replaced)
New side shift ram
New breakout ram
New rod crane raise ram
New hydraulic valve blocks (main & secondary pump control)
New micro control fine feed controller
Majority of gauges replaced
New main rotation shaft seals & speedy sleeves
New rotation torque control cartridge
New hammer oiler pump
New seats and O-rings in majority of valve banks
Air Compressor System:
New air/oil separator filter
New oil stop valve
Castrol Aircoil 68 synthetic oil
New filters
Recently serviced by Midcoast Compressors
Truck Details:
Make: MAN
Year: 1997
Kilometres: 200,000
Configuration: 8x8
Transmission: Reconditioned 18-speed gearbox
Kevrek 1500 Hiab crane with winch & remote umbilical control
Truck Recent Works / Upgrades:
Radiator back flushed
New water pump & fan belts
Brake boosters replaced on all wheels
New four-way valve & brake pedal valve
Rebuilt truck compressor
New air seat system (driver)
New air diff & cross-lock valves
New clutch, flywheel & pressure plate
New bearings & seals in Dana drive box
New oil pump in Dana drive box
New tailshaft universals
New power steering ram
New tyres all round
Ball joints and rubbers replaced as required
Recent pit inspection passed
Compliance / Use:
7 months plant registration remaining
No overhang permits required (within legal length)
Additional Info:
Fully rebuilt and extensively upgraded rig and carrier combination
Strong mechanical condition with significant recent investment
Location: New South Wales, Australia
Why Buy from Us?
- Australian dealers and private sellers
- Indicative finance on every priced listing
- Read our buyer safety guide
Key Features
UsedCondition
Drilling & UndergroundBody
OtherColour
NSWState
Technical Specifications
Basic Details
- Condition
- Used
- Category
- Drilling & Underground
- Drilling & Underground Subcategory
- Drilling Rigs
Machinery Details
- Colour
- Other
- Warranty
- No
